883-BC
Self-Educting Monitor Nozzle
Features
- Transform a water monitor into a foam station without additional equipment
- Designed for use with Class A and B foam
- Combination of straight stream and variable fog patterns
- Interchangeable foam orifice inserts enable variable foam proportioning
- Heavy-duty corrosion resistant brass construction
- Optional drum pick up kit comes with 1m rigid PVC tube with shutoff capability and 9' pickup hose
- Optional isolation valve for shutoff capability
Specifications
Style: 883-BC |
Product Name: Self-Educting Monitor Nozzle |
Flow Rate: 225 GPM (850 LPM) |
Operating Pressure: 100 psi (7 bar) |
Inlet: 1-1/2" (38 mm) |
Foam Proportioning: 3%, 6% |
Material: Brass |
Length: 6.3" (160 mm) |
Weight: 9.9 lbs (4.5 kg) |
Compatible Products: 605 |
