889
Self-Educting Monitor Nozzle
Features
- Transform a water monitor into a foam station without additional equipment
- Designed for use with Class A and B foam
- Combination of straight stream and variable fog patterns
- Interchangeable foam orifice inserts enable variable foam proportioning
- Durable lightweight aluminium alloy construction
- Optional drum pick up kit comes with 8' pickup hose
- Optional isolation valve for shutoff capability
Specifications
| Style: 889 |
| Product Name: Self-Educting Monitor Nozzle |
| Flow Rate: 1000 GPM (3800 LPM) |
| Operating Pressure: 100 psi (7 bar) |
| Inlet: 2-1/2" (65 mm), Quick Connection |
| Foam Proportioning: 1%, 3% |
| Material: Alloy |
| Length: 9.5" (241 mm) |
| Weight: 11.8 lbs (5.4 kg) |
| Compatible Products: 633, 655, 622-3, 935, 955, 230 |
